12 Fiber MTP Module

OPTICO yog ib qho ntawm cov ua lag luam MTP Module thiab fiber ntau optic Cheebtsam hauv Shenzhen, Suav. Peb muaj kev paub ntau tshaj 12 xyoos hauv daim teb no. Txhua yam khoom siv txais cov khoom nruj me ntsis hauv kev tsim khoom thiab tshuaj ntsuam xyuas, ua kom muaj kev ua haujlwm zoo thiab ua kom cov khoom lag luam zoo, thiab kev nyab xeeb thiab kev ntseeg tau kom ntseeg tau siv lub sijhawm ntev ntawm cov khoom ......

Xa kev nug

Ces

12 Fiber ntau MTP module

Qhov chaw ntawm Keeb Kwm: Shenzhen, Suav

Hom Lub Npe: OEM

Tus Qauv Zauv: 12 fibers LC MTPModule LGX lub thawv

Hom: FTTx Solutions

Tus naj npawb ntawm Fiber: 12F

Kev Siv: FTTH

Cov khoom npe: 12 Fiber MTP module

Daim ntawv thov:

FTTH FTTB FTTX Network

Xim: Dub

Hom Fiber: SM / MM / OM3

Cov Khoom Txuas Txuas: LC SC

Lub sijhawm:>=500 zaug

Fiber suav: 12 Tub ntxhais

Adapter: LC, MTRJ lossis SC adapter

Daim ntawv pov thawj: ISO9001

Muaj peev xwm muab lus: 10000 Daim / Daim Ib Lub Lis Piam

Ntim Cov Lus Qhia: 1 pcs / poly hnab / thawv sab hauv, tsim nyog kom muaj nuj nqis rau ib lub thawv

Chaw nres nkoj: Shanghai Chaw nres nkoj, Suav

12 Fiber MTP module

12 Fiber MTP module 2

Khoom Piav Qhia

1.MPO daig kab hluav taws xob cov qauv siv tau los faib cov 12 fibers MPO cov khoom sib txuas ntawm lub davhlau ua ntej lub davhlau yaig xaus rau qhov yooj yim los yog duplex tus txheem txuas.
2.Yog siv qhov yooj yim lossis duplex patch qaum, cov zis tawm tuaj yeem txuas ncaj qha nrog cov khoom siv, thav duab lossis tus neeg siv qhov kawg.
3.Txhais kev hloov ntawm tus qauv no yog pom los ntawm ib tus tub ntxhais lossis ob chav tub ntxhais qhov chaw nres nkoj hauv module pem hauv ntej, 12 tub ntxhais SC yooj yooj yim thiab LC duplex txuas yog xaiv tau, ib lossis ob lub tshuab hluav taws xob tau teeb tsa rau sab nraub qaum, nodule yog kev hloov hluav taws xob txuas, txuas ncaj qha rau module pem hauv ntej. vaj huam sib luag nrog qaum txuas ntawm lub zog ntxiv.

Nta:

1.Qhov vaj huam sib luag pem hauv ntej tau nruab nrog LC, MTRJ lossis SC adapter, lub vaj huam sib luag sab nraud ua ke ntawm MPO adapter.
2. Txais yuav qhov zoo tshaj plaws engineering plastics thiab aluminium alloy cov ntaub ntawv, nrog electrostatic yas-txau rau saum npoo, ua rau nws zoo nkauj hauv kev saib xyuas thiab kev siv yooj yim.
3. MPO ntsej muag phaj tuaj yeem hloov kho yooj yim.
4. Muaj cov cim nyob rau ntawm sab xub ntiag ntawm txhua qhov chaw nres nkoj, thiab tuaj yeem txheeb tau yooj yim.
5. Kev tsim kho sai thiab yooj yim, hloov kho hauv kev teeb tsa thiab yooj yim rau kev tswj hwm.

Cov ntaub ntawv txheej txheem

Hom	Ib Hom		Ib Hom		Ntau hom
	(APC Polish)		(UPC Polish)		(UPC Polish)
Fiber ntau suav	8,12,24 thiab lwm yam.		8,12,24 thiab lwm yam.		8,12,24 thiab lwm yam.
Hom Fiber	G652D, G657A1 thiab lwm yam.		G652D, G657A1 thiab lwm yam.		OM1, OM2, OM3 thiab lwm yam.
Kev Poob Siab Loj Tshaj Plaws	Cov neeg tseem ceeb	Txuj Ci	Cov neeg tseem ceeb	Txuj Ci	Cov neeg tseem ceeb	Txuj Ci
Tsawg poob	Tsawg poob		Tsawg poob		Tsawg poob
	≤0.35 dB	0.75dB	≤0.35 dB	0.75dB	≤0.35 dB	0.60dB
Rov Qab Yuam Kev	≥60 dB		≥60 dB		NA
Lub sijhawm ruaj	500 lub sijhawm		500 lub sijhawm		500 lub sijhawm
Kev khiav hauj lwm kub	-40℃~ +80℃		-40℃~ +80℃		-40℃~ +80℃
Xeem Ntawv Wavelength	1310nm		1310nm		1310nm
