Lub 1550nm quasi qhov chaw tso zis ncaj ncaj muaj cov khoom lag luam zoo, tsis ntsaws poob thiab ruaj khov siab. Lub teeb pom kev loj yog 200um ~ 800um thiab lub zog tuaj yeem ncav cuag 30W. Muaj ntau hom kev kho qhov muag fiber ntau.
Parameters | Chav nyob | Tus nqi |
Chaw Wavelength | nm ua | 1550 los yog Kev Qhia Tshwj Xeeb |
Kev Ua Haujlwm Wavelength Ntau Yam | nm ua | ±30 |
Max. Insertion Loss ntawm 23 ℃ | dB | 0.20 |
Min. Beam puag ncig | % | 90 |
Min. Rov Qab Poob (Cov Tswv Yim /Tawm Tawm) | dB | 5tab 0 |
Nominal Output Beam Diameter (1/e2) | hli | 200umto800 um lossis Tshwj Xeeb |
Max. Qhov Nruab Nrab Kho Qhov Muag | W | 20 los yog Kev Qhia Tshwj Xeeb |
Max. Peak Power rau ns Pulse | kWs | 10 lossis Tshwj Xeeb |
Kev Ua Haujlwm Kub | ℃ | +5~+55 |
Cia Kub | ℃ | -5~+75 |
Cov ntawv thov:
Fiber optic sim |
Laser nqaj kawm tuab si lug |
Fiber rau Fiber Coupling |
Nta:
Tsawg Insertion Loss |
Poob Siab Poob |
High Stability& Kev ntseeg siab |
Chaw Wavelength | 1550=1550nm, SSSS=Qhia meej |
Ua haujlwm nrug | 15 hli |
Beam Txoj kab uas hla | 200 hli-800 hli |
Hom Fiber | 009=DCkavin: SM15-PS-U25D） |
Pob Dimension | 0=φ2.78*10mm 5=.81.8*8mm |
Fiber ntev | 1=0.5m, 2=1m, S=Tshwj xeeb |
Lub Hwj Chim Nruab Nrab | 10=10W, 20=20W, 30=30W, SS=Tshwj Xeeb |
Lub Hwj Chim Fais Fab | 10=10kW, 20=20kW No=00 |
